Eco-Smart Plus Energy Recovery Ventilators

Short Description:

Model: XHBQ-D1.5DDCTPA ~ XHBQ-D20DCTPA
Airflow: 150-2000 m³/h
Introduction: ERP 2018 compliant
Brushless DC motor
Crossflow heat exchanger
Certification: ce eco iso


Product Detail

Tags

New Eco-smart Plus ERV Energy Recovery Ventilator is upgraded to comply with ERP2018. The fans built-in are more efficient, energy consumption reduces by up to 50%. The intelligent controller is improved for more reliable and user friendly operation. Ideal ventilation solutions for energy efficient buildings to reduce energy consumption while achieving comfort indoor climate.

2

Main Feature of Eco-Smart Plus ERV Energy Recovery Ventilators:

  1. Wide range air volume from 150m3/h to 2000m3/h, 10 speeds control;
  2. High efficiency brushless DC motor, ERP 2018 compliant;
  3. High efficiency counterflow heat exchanger, efficiency up to 80%;
  4. Auto summer bypass, auto winter defrost, weekly time, RS485 integrated (BMS);
  5. Optional CO2 sensor to control CO2 concentration;
  6. Multiple auto defrosting mode, outdoor operation temperature down to -15 ℃.

Watch Video of DCTP series ERV Maintenance

Specifications of Eco-Smart Plus ERV Energy Recovery Ventilators:

Model Rated
Air
Flow
(m3/h)
Rated
E.S.P
(Pa)
Enthaply efficiency % Temperature
efficiency %
Noise
dB(A)
Voltage
(V)
Power
Input
(W)
Weight
(kg)
Cooling Heating
XHBQ-D1.5DCTPA 150 75 63-70 70-76 75-82 31.5 220 26 25
XHBQ-D2.5DCTPA 250 85 63-73 70-75 75-82 34.5 220 46 29
XHBQ-D3.5DCTPA 350 90 66-72 69-75 75-84 37.5 220 60 37
XHBQ-D5DCTPA 500 100 62-74 67-75 75-86 39 220 88 43
XHBQ-D6.5DCTPA 650 85 62-70 68-73 75-84 39.5 220 114 64
XHBQ-D8DCTPA 800 130 65-74 71-77 75-84 42 220 186 71
XHBQ-D10DCTPA 1000 110 65-74 71-78 75-85 43 220 243 83
XHBQ-D15DCTPA 1500 75 65-74 71-77 75-84 50 220 372 165
XHBQ-D20DCTPA 2000 60 65-74 71-78 75-85 51.5 220 486 189
